Body is high quality galvanized sheets which are joined to each other with screw.

Electro Motor that is used in fan coils is single shaft or double shaft with three speeds (low, medium and high) with thermal Class B and IP 20. They have thermal protection, if the device is overheated; the fan is turned off and switched on after cooling.

Fans are centrifuge and made of ABS plastic. They are balanced statically and dynamically and have minimum noise level.

Insulation the EPS insulation is used to prevent loss of energy and reduce the noise. The thickness of elastomeric insulation is 4 mm in fan coil models HR, SV, SB and 10 mm thickness of EPS insulation in cassette types.

Coil is made of copper tube 3/8″ with aluminum fin and brass collector. the coil is 3 row with 14 fpi fin, it shall be rinsed with a spe cial degreasing solution after manufacture and hydro tested in 190psig pressure

Filter in according to current world standards is made of propylene (PP). Its efficiency is more than aluminum filters and less pres sure drop. It is washable and has long life.

Pan is insulated on inside or outside surface to prevent condensation with 4mm thickness insulation.
